FM 200 Fire Suppression system

Name: FM 200 Fire Suppression system
Brand: ASHA ENTERPRISE
Price: 70000.0 INR
Availability: InStock

Price 70000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

FM 200 Fire Suppression system Specification

Voltage
24V DC (typical for actuation systems)

Light Source
Non-Applicable

Power
Typically less than 50W for control panel

Feature
Automatic detection and actuation, electrical integration, rapid discharge, non-residual clean agent, safe for electronics

Type
FM 200 Fire Suppression System

Raw Material
FM-200 (Heptafluoropropane) gas with high-pressure steel or aluminum cylinder

Size
Modular, suitable for panel protection or small areas

Length
Dependent on system design and area of installation

Width
Varies by cabinet/controller design

Thickness
Non-Applicable (Cylinder wall thickness as per rated pressure)

Density
6.36 Gram per cubic centimeter(g/cm3)

Thermal Conductivity
Non-Applicable (Gas extinguishing agent)

Water Absorption
Non-Applicable (Gas-based system)

Water Content
0% (Dry chemical agent)

Agent Chemical Name
HFC-227ea (Heptafluoropropane)

Residue
Zero residue, safe for sensitive equipment

Refillable
Yes, after discharge

Noise Level
Low, suitable for electronic and sensitive areas

Discharge Time
Less than 10 seconds

Application Areas
Server rooms, electrical panels, data centers, telecommunications, control rooms

Cylinder Capacity
1 kg to 50 kg or custom

Extinguishing Mechanism
Heat absorption and interruption of combustion chain reaction

Approvals/Certifications
UL, FM, LPCB, CE (system/model dependent)

Installation Orientation
Wall-mounted or panel mounted

Detection Method
Electrical, heat, or smoke detector activated

Cylinder Material
Seamless steel or aluminum

Operating Pressure
25 Bar (360 psi) or 42 Bar (609 psi), cylinder dependent

Environmental Impact
Ozone friendly (ODP = 0), low atmospheric lifetime

FM 200 Fire Suppression system About

FM 200 Fire Suppression System

FM 200 Fire Suppression System is a clean agent fire protection system designed for rapid and effective fire suppression in areas where sensitive equipment and valuable assets need protection. FM 200 (HFC-227ea) is a clean, electrically non-conductive extinguishing agent that suppresses fire quickly without leaving residue.

The system is suitable for protecting electrical, electronic and critical equipment where conventional water-based fire suppression may cause damage.

Key Features:

Fast and effective fire suppression
Clean and residue-free extinguishing agent
Electrically non-conductive
Suitable for sensitive electrical and electronic equipment
Space-saving and easy to maintain
Minimal cleanup after discharge
Designed for automatic fire detection and suppression
Suitable for enclosed protected areas

Applications:

Server Rooms
Data Centers
Control Rooms
Electrical & Electrical Panel Rooms
UPS Rooms
Telecom Rooms
IT Equipment Rooms
Control & Automation Rooms
Archives and other critical equipment areas

Product Name:

FM 200 Fire Suppression System

Keywords:

FM 200 Fire Suppression System, FM200 Fire Fighting System, FM 200 Gas Suppression System, FM200 Clean Agent System, Fire Suppression System, Gas Based Fire Suppression System, Automatic Fire Suppression System, Clean Agent Fire Extinguishing System, Data Center Fire Suppression System.

Advanced Protection for Critical Spaces

FM 200 systems ensure the safety of high-value equipment and sensitive electronics by providing rapid, non-intrusive fire suppression. The clean agent leaves zero residue, meaning there is no need for post-discharge cleanup or risk of damage to hardware and data. The system can be tailored for use in small enclosures or larger rooms, and offers low noise operation, making it ideal for data centers, control rooms, and telecommunication facilities.

Efficient Detection and Fast Response

FM 200 fire suppression is triggered automatically upon detection of heat, smoke, or an electrical signal. The suppression agent is discharged in less than 10 seconds, minimizing fire damage and downtime. The system integrates with your existing electrical infrastructure using 24V DC actuation, ensuring prompt action with minimal manual intervention. Seamless steel or aluminum cylinders are designed for wall or panel mounting, ensuring space-efficient installation.

Environmentally Considerate Design

Utilizing HFC-227ea, the FM 200 system offers a zero ozone depletion potential (ODP = 0) and a low atmospheric lifetime. The clean agent is safe for occupied spaces and does not contribute to harmful environmental effects. With international certifications like UL, FM, LPCB, and CE, you can be assured of both safety and regulatory compliance for your fire protection requirements.

FAQ's of FM 200 Fire Suppression system:

Q: How does the FM 200 Fire Suppression System extinguish fires?

A: The FM 200 system works by quickly absorbing heat and interrupting the combustion chain reaction, both essential mechanisms for extinguishing a fire. Its discharge reduces the energy available to the fire, bringing the threat under control without damaging sensitive electronic equipment or leaving any residue.

Q: What are the benefits of choosing FM 200 over water-based suppression systems?

A: FM 200 is a waterless, clean agent solution that evaporates without leaving residue, making it ideal for environments housing electronics or delicate machinery. In comparison to water-based systems, it eliminates the risk of water damage and ensures faster restoration of normal operations.

Q: When and where should an FM 200 system be installed?

A: The FM 200 system is recommended for environments such as server rooms, electrical panels, data centers, control rooms, and telecommunication facilities-any area where equipment could be severely damaged by water, powder, or foam-based suppression agents. Installation can occur in new constructions or retrofitted into existing premises.

Q: What is the process for detecting and activating the FM 200 system?

A: The system uses electrical, heat, or smoke detectors integrated with a control panel. When a fire is detected, the system automatically triggers the rapid release of the suppression agent within 10 seconds, helping to minimize potential fire damage and downtime.

Q: How is the FM 200 agent stored and delivered?

A: The fire suppression agent, HFC-227ea, is stored in seamless steel or aluminum high-pressure cylinders. Depending on the application, cylinder capacities can range from 1 kg to 50 kg, and the modular design allows for both wall-mounted and panel-mounted installation.

Q: Can the FM 200 cylinders be refilled after activation?

A: Yes, after a system discharge, FM 200 cylinders can be refilled by authorized distributors or service providers. This makes maintenance straightforward and cost-effective, ensuring ongoing fire protection for your critical space.
