NOVAC 1230 FIRE SUPPRESSION SYSTEM

Name: NOVAC 1230 FIRE SUPPRESSION SYSTEM
Brand: ASHA ENTERPRISE
Price: 50000.0 INR
Availability: InStock

Price 50000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

NOVAC 1230 FIRE SUPPRESSION SYSTEM Specification

Features
Environmentally safe, electronics-friendly, zero ozone depletion potential, low GWP

Connectivity Type
Panel-based electrical connectivity

Control Type
Automatic and Manual Control

Working Temperature
0C to +54C

Coating Type
Corrosion-resistant Powder Coated Cylinder

Coverage Area
Varies based on system design, typically 50 to 300 sq.m. per cylinder

Fire Extinguisher Type
Fixed (total flooding) Gas Suppression System

Operating Pressure
25 bar (360 psi) nominal

Installation Type
Floor-mounted with wall-mount or vertical mount option

Mounting Type
Floor mounted with bracket restraint

Shape
Cylindrical

Product Type
SERVER ROOM SUPPRESSION SYSTEM

Fire Class
Class A, B, C

Voltage
Control panel operates at 230V AC / 24V DC

Energy Efficiency Rating
Non-applicable (non-power consuming device)

Technology
Clean Agent Fire Suppression System

Application
SERVER ROOM

Max Flow Rate
Specified as per design and application (typically up to 1000 lpm depending on system layout)

Diameter
Standard cylinder diameters vary (consult manufacturer)

Capacity
Varies (Available in 10L, 20L, 40L, and custom sizes)

Pressure
Standard 25 bar (360 psi) charging pressure

Agent Type
NOVEC 1230 (FK-5-1-12)

Alarm Output
Audible & Visual Alarm with automatic system isolation

Maintenance
Annual Inspection and as per NFPA 2001

Discharge Time
10 Seconds or less

System Response Time
< 30 seconds depending on detection type

Pipe Material
Stainless Steel SCH40/SCH80 or as specified

Refilling Life
Up to 10 Years (subject to periodic inspection)

Safety
Non-toxic, safe for personnel, non-corrosive

Cylinder Material
High Strength Steel

NOVAC 1230 FIRE SUPPRESSION SYSTEM About

The NOVEC 1230 fire suppression system is a clean agent system that rapidly extinguishes fires by absorbing heat, leaving no residue, and ensuring safety for people, property, and the environment.

How NOVEC 1230 Works

NOVEC 1230 uses 3M Novec 1230 fluid, a fluorinated ketone, as its fire-extinguishing agent. Stored as a liquid under pressure with nitrogen, it is released as a gas when the system detects a fire through heat or flame sensors. The agent works primarily by absorbing heat from the fire, interrupting the combustion process without significantly reducing oxygen levels, allowing occupants to safely exit the area during discharge 119firecontrol.com+2. Unlike water-based systems, it does not damage sensitive electronics, documents, or artwork

Comprehensive Fire Protection for Sensitive Electronic Areas

The NOVAC 1230 Fire Suppression System is purpose-built for facilities such as server rooms, where safeguarding electronic assets is critical. By using environmentally safe NOVEC 1230 agent, which is non-toxic and non-corrosive, the system ensures maximum protection without damaging sensitive equipment or threatening personnel safety.

Fast and Effective Fire Suppression

With a discharge time of 10 seconds or less and a system response time of under 30 seconds, the NOVAC 1230 system activates swiftly to stop fire at its early stage. This rapid response minimizes damage, supports business continuity, and provides peace of mind for operators of critical infrastructure.

Low Maintenance and Long Service Life

Periodic inspections and annual maintenance, as outlined by NFPA 2001 guidelines, help keep the NOVAC 1230 system at peak performance. Featuring up to 10 years of refilling life and corrosion-resistant powder-coated cylinders, this system is designed for reliability and longevity.

FAQ's of NOVAC 1230 FIRE SUPPRESSION SYSTEM:

Q: How does the NOVAC 1230 Fire Suppression System operate during a fire event?

A: The system detects fire through automatic sensors or manual activation, triggers both audible and visual alarms, and rapidly releases the NOVEC 1230 agent through stainless steel piping, extinguishing the fire within 10 seconds without residue or equipment damage.

Q: What types of fires can the NOVAC 1230 system effectively suppress?

A: The system is engineered to protect against Class A (ordinary combustibles), Class B (flammable liquids), and Class C (electrical) fires, making it especially suitable for electronic assets and data centers.

Q: When is maintenance required for the NOVAC 1230 system?

A: Routine maintenance should be performed annually as per NFPA 2001 standards, alongside periodic inspections to ensure reliable system operation and to maintain the agent's shelf life of up to 10 years.

Q: Where can the NOVAC 1230 system be installed?

A: It is ideal for critical areas such as server rooms, data centers, communication facilities, and other spaces containing high-value electronic assets. Installation configurations can be tailored to specific room sizes and layouts.

Q: What is the process for refilling or servicing the NOVAC 1230 system?

A: The system is designed for easy refilling, typically at intervals up to 10 years, subject to regular inspections. Only authorized and trained service providers should handle refilling and servicing to maintain safety and compliance.

Q: Can the NOVAC 1230 system be integrated with existing building alarm systems?

A: Yes, it uses panel-based electrical connectivity and can be configured to communicate with building management and alarm systems for coordinated response and enhanced safety.

Q: What are the benefits of choosing this system over traditional fire extinguishing solutions?

A: NOVAC 1230 offers rapid suppression without leaving residue, is non-corrosive and non-toxic, safe for personnel, and environmentally friendly with zero ozone depletion and low global warming potential, thus ensuring protection for both people and sensitive equipment.
